This site contains my collection of vintage transistors and diodes, most of them included with their original package or sleeves. The devices are produced in the late fifties and early sixties except the MOSFET's from Sony they where made in 1975. Enjoy the collectables and click on the picture links for more details. Suggestions regarding these transistors are welcome. I'm always looking for new semiconductor items to complete my collection, so if you would like to sell or exchange something, please contact me, jan@transparentsound.com.
Thanks to Ed Millis, Author of the book "TI, the Transistor and Me" for his great donations of a lot Texas Instruments Transistors.
| TN59 | : | TN59, Germanium Transistor for Hearing aid units, made by Ed Millis himself! (New) | |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 14th week of 1956 | |
| Package, Case style | : | Very small- TO-22 case in envelope | |
| Spec's | : | Unknown, (Thanks to Rick Hirsh for the information) | |
| Photo's | : | Picture1, Picture2, Picture3 (Donated by Ed Millis US) |
| Experimental Transistors | Type | : | Experimental Transistors, Germanium PNP Transistor Low Frequency (New) |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Early fifties, no identification on case | |
| Package, Case style | : | TO-22-var in envelope (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2 (Donated by Ed Millis US) |
| J11 | Type | : | J11,Germanium PNP Transistor Low Frequency (New) |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 1955, week-43 | |
| Package, Case style | : | TO-22-var in envelope (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3 (Donated by Ed Millis US) |
| 201 | Type | : | 201,Germanium PNP Transistor Low Frequency (New) |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Early fifties, double brown dots on top | |
| Package, Case style | : | none, TO-22-var (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4 |
| 300 | Type | : | 300, germanium PNP Transistor Low Frequency (New) |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 1955, week-45 | |
| Package, Case style | : | TO-22-var in envelope (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3 (Donated by Ed Millis US) |
| 904 | Type | : | 904,Silicon NPN Grown Junction Transistor Low Frequency |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 1959, week-04 serial no. 980709 | |
| Package, Case style | : | none, TO-22-var (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3 The 900-series was the first commercially Silicon Junction Devices of Texas Instruments. |
| 950-1 | Type | : | 950-1,Silicon NPN Grown Junction Transistor Low Frequency (New) |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 9-10 = 1959, week-10 | |
| Package, Case style | : | none, TO-22-var (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3 |
| 951 | Type | : | 951,Silicon NPN Grown Junction Transistor Low Frequency |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 9-10 = 1959 week-10 | |
| Package, Case style | : | none, TO-22-var (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3 |
| J213 | Type | : | J213,Silicon NPN Grown Junction Transistor Low Frequency |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 007 = September 1960 | |
| Package, Case style | : | none, TO-22-var (I'm looking for technical data) | |
| Spec's | : | Vcbo=?V, Vceo=?V,Hfe=?, Ic=?A, P=?W, Icbo(max)=?mA, ft=?MHz, Cobo=?pF, used in Low frequency applications | |
| Photo's | : | Picture1, Picture2, Picture3 (Donated by Gerard Duperray France) |
| 1N456 | Type | : | 1N456, Low Leakage Diode |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 0-16 = week16, 1960 | |
| Package, Case style | : | Carton box, DO-35 | |
| Spec's | : | BV=30V, IRmax=25nA, VRmax=25V, VFmax=1.0V, IFmax=40mA, Cmax=10pF | |
| Photo's | : | Picture1, Picture2 (Donated by Rose Freeman US) |
| 2N119 | Type | : | 2N119, NPN Silicium Low Power Transistor. |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 416 = week16, 1964 | |
| Package, Case style | : | Carton box, TO-22var | |
| Spec's | : | Vcbo=45V, Vceo=?V,Hfe=56, Ic=25mA, P=150mW, Icbo(max)=2uA, ft=6MHz, Cobo=7pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Note: The 2N117-2N120 where the first commercial TI transistors with JEDEC code. |
| 2N389 | Type | : | 2N389, NPN Silicium Power Transistor, 140x140mil Chip. Single Diffused Process. |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 0-16 = week16, 1960 | |
| Package, Case style | : | Carton box, TO-53 with clip leads | |
| Spec's | : | Vcbo=?V, Vceo=60V,Hfe=12-60, Ic=3A, P=85W, Icbo(max)=10mA, ft=1MHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, (Donated by Ronald Werner from Norway). General Purpose Power Switch and Amplifier. Industrial and Military usage. |
| 2N458A | Type | : | 2N458A, PNP Silicium Power Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Mid sixties | |
| Package, Case style | : | Carton box, TO-3 | |
| Spec's | : | Vcbo=-80V, Vceo=-40V,Hfe=30-90, Ic=5A, P=?W, Icbo(max)=?uA, ft=?MHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2 |
| 2N498 | Type | : | 2N498, NPN Silicium Medium Power Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 9-39 = week39, 1969 | |
| Package, Case style | : | Carton box, TO-5 | |
| Spec's | : | Vcbo=100V, Vceo=100V,Hfe=12-36, Ic=?A, P=4W, Icbo(max)=10uA, ft=?MHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5, (Donated by Ronald Werner from Norway) |
| 2N542 | Type | : | 2N542, NPN Silicium Low Power Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Early sixties | |
| Package, Case style | : | Carton Sleeve, TO-5 | |
| Spec's | : | Vcbo=30V, Vceo=30V,Ic=25mA, P=200mW, Icbo(max)=500nA, ft=10MHz, Cobo=20pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5, Picture6 |
| 2N743 | Type | : | 2N743, NPN Silicium Low Power High Frequency Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 203, 1963 week 2 | |
| Package, Case style | : | Carton Sleeve, TO-18 | |
| Spec's | : | Vcbo=20V, Vceo=12V,Ic=200mA, Hfe=20-60, P=300mW, Icbo(max)=1uA, ft=1MHz, Cobo=5pF, T(on)max=16nS, T(s)max=14nS, T(off)max=24nS | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4 (Donated by Rose Freeman US) |
| 2N1149/2N1150 | Type | : | 2N1149/2N1150, NPN Silicium Grown Junction Transistor, Low Power |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Early sixties | |
| Package, Case style | : | ?, TO-22var | |
| Spec's | : | Vcbo=45V, Hfe=20(2N1149), Hfe=40(2N1150), Ic=25mA, P=150mW | |
| Photo's | : | Picture1, Picture2, Picture3, |
| 2N1155 | Type | : | 2N1155, NPN Silicium Grown Junction Transistor, Low Power Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Week26, 1960 | |
| Package, Case style | : | Carton Sleeve, TO-22var | |
| Spec's | : | Vcbo=80V, Hfe=?, Ic=50mA, Icbo=6uA, P=750mW | |
| Photo's | : | Picture1, Picture2, Picture3, |
| 2N1724 | Type | : | 2N1724, NPN Silicium Grown Junction Transistor, Low Power Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 428, Week28, 1964 | |
| Package, Case style | : | Carton box, TO-61 | |
| Spec's | : | Vcbo=175V, Vceo=80V,Hfe=30-120, Ic=5A, P=50W, Icbo(max)=5mA, ft=10MHz, Cobo=550pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, (donated by Ronald Werner from Norway) |
| 2N1893 | Type | : | 2N1893, NPN Silicium Medium Power High Voltage |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 513A, Week13, 1965 | |
| Package, Case style | : | Carton sleeve, TO-5 | |
| Spec's | : | Vcbo=120V, Vceo=80V,Hfe=40-120, Ic=500mA, P=800mW, Icbo(max)=5mA, ft=50MHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, (donated by Ronald Werner from Norway) |
| 2N3819 | Type | : | 2N3819, N-Channel J-FET |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 6550A, Week?, Year? | |
| Package, Case style | : | Carton sleeve, TO-92 | |
| Spec's | : | DG=25V, DS=25V, Reverse GS=-25V, IG=10mA, P=200mW, Icbo(max)=5mA, ft=50MHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, (Donated by Rose Freeman US) |
| TIX611 | Type | : | TIX611, NPN Silicium Transistor |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | Unknown | |
| Package, Case style | : | Carton sleeve, TO-18 | |
| Spec's | : | Vcbo=120V, Vceo=?V,Hfe=?, Ic=500mA, P=300mW, Icbo(max)=?mA, ft=?MHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2 (Donated by Rose Freeman US) |
| T1 | : | T1, Silicon diode | |
|
|
Manufacturer | : | Texas Instruments |
| Year | : | 14th week of 1956 | |
| Package, Case style | : | Very small TO-22 caseNone | |
| Spec's | : | Unknown, (Thanks to Rick Hirsh for the information) | |
| Photo's | : | Picture1, Picture2, |
