Honeywell Transistors / Diodes Collection
This site contains my collection
of vintage transistors and diodes, most of them included with their original
package or sleeves. The devices are produced in the late fifties and early sixties
except the MOSFET's from Sony they where made in 1975. Enjoy the collectables
and click on the picture links for more details. Suggestions regarding these
transistors are welcome. I'm always looking for new semiconductor items to
complete my collection, so if you would like to sell or exchange something,
please contact me,
jan@transparentsound.com.
Thanks to Chuck Anderson who give me the possibility to get a beautiful transistor collection from the legacy of his father Ray Anderson. He was at Honeywell from the early 40s, installing and testing autopilots during WWII. In the 1950s, he was "on loan" to GE to help with the controls on the first nuclear subs. After that, he was with the semiconductor division, first as sales manager, then as assistant to the director of that division until it was phased out. His background was in physics and electrical engineering.
| Undifined Transistors | Type | : | Undifined Transistors, Honeywell Germanium Power Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | Metal Can | |
| Spec's | : | Vceo(max)=-30V, Vcbo(max)=-60V, Hfe=14, Ic=-800mA, Icbo=?mA, P=20W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Note: First commercial Power Transistor of Honeywell with JEDEC code. |
| 2N8 | Type | : | 2N8-701, Honeywell Germanium Power Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | early fifties | |
| Package, Case | : | Metal Can | |
| Spec's | : | Vceo(max)=-30V, Vcbo(max)=-60V, Hfe=14, Ic=-800mA, Icbo=?mA, P=20W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Note: First commercial Power Transistor of Honeywell with JEDEC code. |
| 2N57 | Type | : | 2N57, Honeywell Germanium Power Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | TO-10, Metal Can | |
| Spec's | : | Vceo(max)=-30V, Vcbo(max)=-60V, Hfe=14, Ic=-800mA, Icbo=?mA, P=20W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Note: First commercial Power Transistor of Honeywell with JEDEC code. |
| 2N57 | Type | : | 2N57, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | ?, StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, (Thanks to Chuck Anderson). |
| H1 | Type | : | H1, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can in carton box (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, (Thanks to Chuck Anderson). |
| H4 | Type | : | H4, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5 (Thanks to Chuck Anderson). |
| H5 | Type | : | H5, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Week ?, | |
| Package, Case | : | ?, StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4 (Thanks to Chuck Anderson). |
| H6 | Type | : | H6, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | ?, StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4 (Thanks to Chuck Anderson). |
| H10 | Type | : | H10, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can in carton box (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3 (Thanks to Chuck Anderson). |
| H45 | Type | : | H45, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can in carton box (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3 (Thanks to Chuck Anderson). |
| H71 | Type | : | H71, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2 (Thanks to Chuck Anderson). |
| H201 | Type | : | H201, Honeywell Germanium Power Tetrode Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5 |
| H201E1 | Type | : | H201E1, Honeywell Germanium Power Tetrode Transistor |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can in carton box (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5, Picture6 |
| 2N575A | Type | : | 2N575A, Honeywell Germanium Power Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can | |
| Spec's | : | Vceo(max)=-60V, Vcbo(max)=-50V, Hfe=19-42, Ic=-25A, Icbo=7mA, P=187W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5, Picture6 |
| 2N576 | Type | : | 2N576, Honeywell Germanium Power Transistor |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can | |
| Spec's | : | Vceo(max)=-60V, Vcbo(max)=-50V, Hfe=19-42, Ic=-25A, Icbo=7mA, P=187W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3 |
| 2N1501 | Type | : | 2N1501, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | StR-1/4, Metal Can (Who can help me with the technical data?) | |
| Spec's | : | Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?A, Icbo=?mA, P=?W, ft=?kHz, Cobo=?pF | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5 (Thanks to Chuck Anderson). |
| Silicon wafer | Type | : | Silicon wafer, Honeywell Germanium Transistor (New) |
|
|
Manufacturer | : | Honeywell Semiconductors |
| Year | : | Early fifties | |
| Package, Case | : | Envelope (Who can help me with the technical data?) | |
| Spec's | : | one inch diameter, silicon waver | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4 (Thanks to Chuck Anderson). |
